Great flexibility & versatility
The controller has a very high & stable output power, so the models can make a variety of moves without any problems. Regardless of whether it is an aggressive start or a wheelie, a 720 degree flip or a killer jump, the controller also masters high-speed tests with ease. In addition, the controller can be programmed with a wide variety of parameters in order to obtain excellent control of the model and to react as sensitively as possible in the accelerator / brake curve.
Suitable for all weather conditions
Excellent sealing against water and dust make this regulator a weapon in any weather or under any conditions. Regardless of whether it is extremely dusty slopes, wet roads, snow, Fützen or gravel, with the MAX8 it goes on and on.
Advanced and safe electronic switch
This electronic switch has a lifetime of more than 50,000 switching operations and is also completely waterproof and dustproof and also has a shockproof design. This means that problems such as rusty contact points or moisture in the switch are a thing of the past. Nor can it switch itself off after hard landings or accidents like a conventional mechanical switch.
Super built-in BEC
The world's first controller with built-in Super BEC which can provide a maximum output power of up to 15A. In addition, the output voltage can be set between 6V & 7.4V. A wide variety of servos can be operated such as high current (HV) servos in order to maintain maximum control of the model.
Plug & Play
Equipped with 6.5mm gold contact sockets as standard, the plugs of most motors such as those from Traxxas or HPI can be plugged into the controller. The widespread T-connector is already soldered on the battery side, so in most cases the annoying soldering is no longer necessary and the controller can be put into operation immediately.
A few mounting holes are already made on the housing side so that the controller can be easily installed in Traxxas models, for example.
Wide range of applications
This controller is the perfect upgrade choice for most 1/8 Monster Truck models such as Traxxas E-Revo & E-Maxx, HPI Savage or Thunder Tiger E-Mat as well as other 1/8 Monster Trucks that need a performance boost.
Almost maintenance free
The entire controller, with the exception of the fan, is basically maintenance-free. Only the fan cover has to be removed to replace the fan if necessary. It is therefore not necessary to open the housing or the like and the whole process can be carried out quickly and smoothly
Technical specifications:
Battery connector system: | XT90 connector |
Motor socket system: | 6.5mm gold contact |
Cont. / Peak current: | 150A / 950A |
Engine type: | Brushless, sensorless |
Motor Limits Brushless: | 4S LiPo / 12S NiMH: KV = 3000 (4274 size) 6S LiPo / 18S NiMH: KV = 2400 (4274 size) |
LiPo / NiMH cells: | 6-18S NiMH 2-6S LiPo |
Internal resistance: | 0.002 ohms |
BEC output: | 6V / 7.2V with 6A (switchable) |
Fan: | Yes (supply via built-in BEC) |
Programming input: | Fan / PRG input |
ESC programming: | LCD Program Box LED Program Box Set-Up Button |
Size (LxWxH): | 59.8 x 48 x 36.8mm |
Weight: | 173g |
Applications: | 1/8 touring car, buggy, truggy and monster truck with high-end configuration for races |
159,00 €
