Ekstreemne 3S jõudlus. Kompaktne suurus.
See on uuendatud kerega versioon (V2)!
Mini XRT® on tõeline rakett, millel pardal 1/10 skaala Velineon® 3s harjavaba jõuajam ja seda väikeses, kergesti kaasaskantavas formaadis. Mini XRT kannab uhusega enda suurema venna nime saavutades kiiruse 85+ km/h kiiremini kui julgeks arvata. Mini XRT purustab kõik ootused oma suurema skaala omadustega, kuid mahub seejuures kasvõi seljakotti.
Mudeli spetsifikatsioon
| Pikkus: |
376 mm |
| Rööbe: |
279 mm |
| Kliirens: |
27 mm |
| Mass: |
1.81 kg |
| Kõrgus: |
127 mm |
| Teljevahe: |
220 mm |
| Amordi pikkus: |
88 mm |
| Ratta diameeter: |
94 mm |
| Velje diameeter: |
2.1″ (53 mm) väliskülg, 2.6″ (66 mm) sisekülg |
| ESC: |
VXL-3s harjavaba ESC |
| Mootor: |
Velineon 3500 (3500 Kv) harjavaba sensorita elektrimootor |
| Peaülekanne: |
Otseülekanne, keskdiferentsiaaliga |
| Õlekandearv: |
7.36:1 |
| Diferentsiaali tüüp: |
Planetaar, metallist hammakad |
| Gear Pitch: |
32 |
| Shassii materjal ja struktuur: |
Modulaarne nailonkomposiit |
| Pidurid: |
Elektroonilised (mootoriga) |
| Veoskeem: |
Kardaanidega 4WD |
| Roolisüsteem: |
Double-shear bellcrank |
| Rehvid ja veljed: |
Mustad topelt-profiiliga XRT veljed ja veljele liimitud 4″ Gravix rehvid |
| Raadiosüsteem: |
TQi 2.4 GHz (2-kanaliga), TSM |
| Rooliservo: |
Metallhammakatega 2075X |
| Tippkiirus: |
85+ km/h (3S LiPo akuga) |
| Oskuste tase: |
1 |
| Aku pesa: |
113 x 41 x 22 mm |
| Vajalikud patareid: |
4 “AA” (saatjasse) (Ei ole komplektis) |
Müügipakend sisaldab:
- Mini XRT Sõiduvalmis mudel
- Velineon VXL-3s harjavaba mootor & ESC
- 3500 mAh 2S LiPo sõiduaku
- 2A USB-C laadija
- Alustamise kiirjuhend (inglise keeles)
- TQi 2.4 GHz raadiosüsteem
- Hooldustööriistad
Lisaks on vaja (ei ole komplektis):
Omaduste nimekiri
- 40+ mph with included 2-cell LiPo Battery. 55+ mph with optional 3-Cell LiPo Battery (sold separately)
- Clipless Body Mount System
- Quick and easy installation and removal
- Nerf bar channels for side body support
- Reinforced for extra protection against tearing
- Functional rear wing
- VXL-3s Waterproof Electronic Speed Control
- Three programmable drive profiles
- Sport Mode - forward / brake / reverse
- Race Mode - forward / brake
- Training Mode™ - 50% forward / brake / 50% reverse
- Heat sink accepts accessory cooling fan (3340)
- Traxxas EZ-Set® one-button setup
- Built-in two-stage low-voltage detection
- Velineon 3500 Kv Brushless Motor
- Ultra high-temperature sintered neodymium magnets
- Low-maintenance design
- Precision-balanced rotor
- Efficient high-speed ball bearings
- 3500 Kv
- Brilliant blue-anodized finish
- Battery and Charger Included
- High-capacity 2-cell LiPo battery
- 7.4 volts
- 3500 mAh for extended run time
- 2-amp USB-C charger
- iD® technology for faster, safer charging
- TQi 2.4 GHz High Output 2-Channel Radio System
- Programmable multi-function knob
- Adjustable steering and throttle percentage (dual rates)
- Adjustable steering and throttle sensitivity (exponential)
- Adjustable steering and throttle end points
- 5-channel micro receiver (6533) with fail-safe security
- Patented waterproof receiver box with easy-access plug
- Traxxas Stability Management (TSM)
- Improves straight line acceleration and braking on low-traction surfaces
- Maintains steering composure to allow throttle-on powerslides
- Never dulls throttle or slows the truck
- Adjusts from off to 100% assistance from the transmitter
- 1/10 Scale 4X4 Drivetrain
- Full-time shaft-driven 4-wheel drive
- 1/10 scale extreme-duty telescoping driveshafts
- Direct-drive (no transmission)
- Sealed center differential
- Large 32-pitch gears
- Sealed planetary steel-gear differentials (F&R)
- Fixed gear mesh system
- Modular Composite Chassis
- Modular chassis with interlocking front and rear bulkheads
- Absorbs and distributes impact energy
- Easy to service and access components
- Driveline is sealed in the chassis to keep out dirt
- Easy Battery Access
- Battery is protected deep in the chassis
- Battery hold-down pivots for easy access
- More secure than conventional retention systems
- Steering
- 1/10 scale 2075X waterproof high-torque, metal-gear servo
- Heavy-duty double-shear bellcranks
- Cam-operated servo saver
- Suspension
- Heavy-duty, double-shear suspension arms
- Dual-wishbone design
- Extra tough outer suspension components
- Oil-Filled Ultra Shocks™
- 1/10 scale shocks
- Large oil capacity
- Easy to tune
- Bumpers and Skid Plates
- Tough energy absorbing front bumper
- High-angle front skid plate
- Rugged interlocking skid plates
- Smooth undertray eliminates snags
- Integrated nerf bars for side impact resistance
- Wheels and Tires
- New graphite gray mini XRT wheels
- Gravix tires with foam inserts
- Excellent traction on or off the road
- Directional tread pattern for quieter running
- Thick center carcass resists ballooning
- Hex Hardware with Rust-Resistant Black Oxide Coating
- Sealed Ball Bearings
