T-Motor F0803 22000KV FPV Copter Motor (tiny whoop)

SKU: TMO-F0803-22000KV
EAN: 6971360357193
Brand:

Unit: pc
In stock: Temporarily out of stock.

Price:

13,90 €

Description

Product description

The T-Motor F0803 22000KV is a high-performance brushless motor purpose-built for ultra-lightweight Tiny Whoop and micro-FPV drones, weighing in at a mere 2.47g. The extreme 22000KV rating provides explosive thrust and high-RPM power on 1S LiPo/LiHV voltage, making it the premier choice for pilots looking to upgrade their micro quads for aggressive indoor freestyle or tight track racing.

The motor comes factory-fitted with a 33.5mm wire harness ending in a JST-1.25 connector, allowing for solder-free, plug-and-play installation on compatible all-in-one (AIO) flight controllers. Utilizing a standard 3-hole triangular mounting configuration (Ø6.6mm), it drops seamlessly into modern micro frames like the BetaFPV Air65, Air75, or Meteor75 series.

Technical Specifications:

Manufacturer: T-Motor
Model: F0803 22000KV
KV: 22000
Dimensions (Diameter × Length): 10.6 × 15.7 mm
Cable & Plug: JST-1.25, 33.5 mm length
Weight: 2.47 g
Operating Voltage: 1S LiPo / LiHV
Peak Current (60s): 5.46A
Mounting Layout: 3-hole triangular configuration (Ø6.6mm) [BetaFPV 0702 motor mounting pattern screws, BetaFPV Air65 frame motor mount 3 holes]
